Coupling

Coupling == Connection

Change the size or shape of one end; we'll also have to make the same change on the other

Too much coupling is bad

If everything is coupled to everything

then every change requires editing everything

We sell coupling

If there is no coupling, there is no software.

Coding is coupling.

Couple wisely

Not "avoid coupling"

Rather: "make good choices about how and what we couple"

Types of coupling

• We'll go over a bunch
• Rule of thumb: the ones I cover first are less problematic
  • refactor towards the first ones

From "Building Evolutionary Architectures"

From Chapter 5, section "Connascence"

Static vs Dynamic

• static coupling refers to coupling in the code
• dynamic coupling refers to coupling in runtime behavior

Static: Name Coupling

function findHat() {
  // ...
}

function main() {
  findHat();
}

If we rename findHat(), we must update main() or the code won't compile

Static: Type Coupling

function printThisNumber(toPrint: number) {
  // ...
}

function main() {
  printThisNumber(42);
}

If we change the type of toPrint to a string, then we must update main or the code won't compile

Static: Meaning Coupling

Currently, "day 0" means "irrigate once".

function scheduleIrrigation(day: number) { /* ... */ }

function main() {
  scheduleIrrigation(0);
}

If we change the firmware so "day 0" to mean "irrigate every day", then our code still compiles but we will have a problem at runtime unless we also change main.

Static: Position Coupling

function buyAnimals(mice: number, whales: number) {
  // ...
}

function main() {
  buyAnimals(40, 2);
}

If we swap the parameters in buyAnimals, our code will compile even if we don't change main... but we will end up with way too many whales and not nearly enough mice.

Static: Algorithm Coupling

// client
function sendToServer(payload: Payload) {
  http.post('/data', JSON.stringify(payload));
}

// server
function handlePostData(request: HttpRequest) {
  const data = CSV.parse(request.body);
}

If the client encodes JSON but the server expects CSV, the system won't work. The serialization/deserialization algorithms are coupled.

Dynamic: Execution Coupling

const email = new Email();
email.setRecipient('foo@example.com');
email.setSender('me@me.com');
email.send();
email.setSubject('too late');

The methods have execution coupling because they must be called in a certain order

Dynamic: Timing Coupling

// Runs when the app starts
loadData().then(data => {
  globalState.data = data;
})

// One page of the app
function render() {
  this.title = globalState.data.title;
}

If that page loads before the data is set, we will have no title. The code is apparently independent but there is dynamic coupling between these parts of the code.

Dynamic: Value Coupling

const buyerAccount: BankAccount = getBankAccount(buyerUserId);
const sellerAccount: BankAccount = getBankAccount(sellerUserId);

buyerAccount.withdraw(itemPrice);
sellerAccount.deposit(itemPrice);

The buyer and seller account values must change together.

Dynamic: Identity Coupling

This is like static name coupling, except it's at runtime.

Two independent systems must reference the same entity for the overall system to work. Example:

• Configure our SSO provider to redirect to ourwebsite.com?authToken=$TOKEN after a successful authentication
• Our app code must read the query parameter named authToken

So many ways to couple!

So what do we do with this list of coupling types?

Bring the pain forward

• static is less scary than dynamic
• of the static coupling, the ones the compiler catch are less scary
